From the Research Series comes the all-new flagship Integra audio-video receiver, unsurpassed in reference all-in-one home entertainment. Double-skinned and braced chassis provides rigidity for full-floating circuitry, custom shielded power supply, and shielded amplification, all of which harmonize to isolate signals from noise. The result is absolute sonic purity in the quietest passages all the way up to earth-shaking volume levels. Equipped with every convenience for whole-home audiophile sound, the DRX-R1.1 carries the Integra legacy into the future.

Produktbeskrivelse

From the Research Series comes the all-new flagship Integra audio-video receiver, unsurpassed in reference all-in-one home entertainment. Double-skinned and braced chassis provides rigidity for full-floating circuitry, custom shielded power supply, and shielded amplification, all of which harmonize to isolate signals from noise. The result is absolute sonic purity in the quietest passages all the way up to earth-shaking volume levels. Equipped with every convenience for whole-home audiophile sound, the DRX-R1.1 carries the Integra legacy into the future.

Advanced Hybrid Digital Amplifier Design

Modern Design Meets Legendary Performance. Integra amplifier designs have always been known for delivering voluminous loads of current via massive, oversized power supply sections -providing precise speaker control and dynamics. At 140 Watts per Channel (11 channels) at 8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC – the DRX-R1.1 combines this legendary performance with today’s ultra-efficient digital output stages, proprietary filtering technologies, and oversized low pass filter coils- resulting in stunning audio clarity, accuracy and musicality- across the entire audio output range.

DRX_R1_MDD_Top_off

THX Certified Select

The DRX-R1.1 is Certified Select by THX. In order to satisfy THX parameters, 40-60 hours of testing over 2000 data points for AV Receivers to ensure that the DRX-R1.1 is capable of meeting rigorous audio and video performance standards, resulting in reference level, distortion free playback. This goes on to include THX Loudness Plus technology, to bring out intricate details at lower listening levels.

THX

Hi-Resolution Audio Powerhouse

Hear your music library as never before. High-Resolution means studio quality sound recording to extract additional elements, nuances and details far beyond the capabilities of standard CD to virtually put you in the room with your favorite musician. Integra makes it incredibly easy to access and enjoy audio files mastered in high-resolution (up to 192kHz/24-bit) stored on a computer, media server, network-attached storage (NAS) or USB thumb drive with zero loss in audio quality. Virtually every hi-resolution and lossless format is supported- 11.2, 5.6 or 2.8 MHz DSD, Dolby® TrueHD as well as gapless playback of FLAC, WAV, AAC, AIFF, ALAC and WMA files. Three Sharc 32-Bit DSP’s operate at speeds greater than 6 billion operations per second – combined with award winning AKM 32-bit differential Audio DACs (up to 768k / 32-bit) provide more than enough power to accurately and easily handle almost any high resolution audio format in the market today.

Download Hi-Res Music Here

HI-RES Audio

Smooth Analog Signal

Vector Linear Shaping Circuitry (VLSC) – you can definitely hear the difference. In today’s digital audio world- the process of converting digital to analog inevitably introduces pulse noise- distorting the original audio image. and then amplifying it together with the original signal, compromising sound quality. Integra’s exclusive VLSC technology compares the input signal to the outgoing signal and filters out pulse noise. Thus allowing original signal to be regenerated so that the audio signal is the same as what was captured on the recording- faithfully and accurately. This results in the DRX-R1.1 producing a virtually noiseless audio signal across all channels.

Flexible Zone 2 & 3

The DRX-R1.1 features Powered Zone 2 and 3 to bring audio to speakers connected to the receiver in a second and third room. Zone 2 and Zone 3 Pre/Line Out are included for use with an outboard amp. It includes a Zone 2 DAC for HDMI Inputs 1 through 5, Coax and Optical Inputs (2-CH PCM), Network functionality (including all network streaming services), and USB audio sources. There are maximum power and power on volume settings for the Main Zone, Zone 2 and Zone 3 to further customize your listening experience and help get the best performance out of your speakers. The DRX-R1.1 also includes a Whole House Audio Mode- which allows you to turn on and synchronize all audio zones with a single button push of a single button- Now that’s convenience!

Powered_Zone_2&3

4K HDBaseT Port for Multimedia Distribution

The world’s first full 18 Gbps support! The 4K HDBaseT includes 4K/60Hz @4:4:4 / HDCP 2.2, Dolby Vision (up to 4K/30Hz), HDR 10, HLG, and WGC. Audio and video signals can clearly be transmitted up to 328 feet utilizing cat5e/cat6 cable to any certified third party HDBaseT receiver or device that has its own power supply. The POC enables compatibility with more Rx Devices and makes long distance runs to projectors or a second zone easy and reliable. Furthermore, the control of the enhanced HDBaseT can be accessed through both the IR input / IR Output & Bi-directional RS-232 feeds.

HDBseT - Smarthuset AS

Industry-Leading Digital-to-Analog Conversion (DAC)

The Asahi Kasei AK4458 384 kHz / 32-bit high-performance digital-to-analog converter achieves the industry’s best low distortion characteristics using a unique digital filtering process focused on the «original sound» – authoritative, rich, and pure. This ultra-precise DAC unlocks the full potential of virtually any compressed, lossless, or – especially critical today- Hi-res Audio format; maximizing the sonic performance of your favorite music, movies and more. Supported formats include AAC, AIFF, Apple Lossless, Dolby TrueHD, DSD 5.6 MHz, FLAC, LPCM, MP3, OggVorbis, WAV and WMA.

Learn More

384-32-AKM-chip

Object-Based Sound Up to 7.2.4 Channels

With 11.2 channels of instantaneous power, the DRX-R1.1 enables the current maximum Dolby Atmos® and DTS:Xhome-theater layout of 7.2.4 channels in a self-contained component for the ultimate in multidimensional object-based surround sound.

Learn More About Dolby Atmos

Learn More About DTS:X

DTS Play-Fi® Multi-room Audio

The DRX-R1.1 includes DTS Play-Fi technology. DTS Play-Fi is the most widely adopted Whole Home Audio Technology in the marketplace- it puts you in complete control of your Music and allows you to effortlessly stream from your smartphone, tablet, or PC to DTS Play-Fi speakers and devices throughout the home. Stream a Music playlist throughout the entire house while entertaining or simply enjoy your favorite artist or album in a single room- DTS Play-Fi offers better sound quality, greater range and a wider variety of compatible devices than other wireless Whole Home music technologies. Easy to set-up, easy to expand, and easy to enjoy- DTS Play-Fi and Integra- a smart solution.

Learn More About DTS Play-Fi

UltraHD / HDR Connectivity

HDMI specifications and HDCP 2.2 compatibility for the DRX-R1.1, support the latest formats being released in the industry. The latest HDMI specs offer a significant increase in bandwidth (up to 18Gbps) to for full UltraHD support of features such as 4:4:4 color space and 4K/60Hz (2160p), which results in 4 times the clarity of 1080p/60 video resolution. The DRX-R1.1 enables transmission of Dolby Vision, High Dynamic Range (HDR) formats, with BT.2020 support, and provides enhanced picture quality by simultaneously enabling greater detail for both the dark and bright parts of an image.

Stream It Easy

At Integra music is our passion. In keeping with todays world of musical convenience- the DRX-R1.1 includes Chromecast built-in, Apple AirPlay and a plethora of music streaming services such as Spotify Connect, Tidal, Pandora, Deezer and TuneIn Radio. Allowing you to stream virtually any audio signal from a smartphone, tablet or PC to your home theater or living room for powerful sound with ease. Whether its hi-resolution audio files via network or USB, Internet streaming services or listening to music already stored on your smartphone or tablet- the free Integra Control Pro app puts a range of streaming options conveniently at your fingertips- allowing you to easily browse, select, and play from around the home.

How to Set-up & Use Chromecast built-in

Integra_music_full_ logos_no_play-fi_no_BT

App Control

The Integra Control Pro app for iOS, Android, and Kindle devices is a convenient way to control your home entertainment from anywhere within wireless range. The app has a clear graphical interface to control playback, adjust settings and handle content across multiple zones. The app serves hi-res, lossless, and compressed audio files (including 192 kHz/24-bit FLAC, DSD, Apple Lossless, Dolby® TrueHD and more) to the DRX-R1.1 from your mobile devices, and gives it stunning sound.

google
Android-Integra

The Best Build and Flexibility

Integra components are not just built- they are substantially and purposely overbuilt. As a Research Series unit, exceptional design and rigid construction techniques are used throughout- high-quality anti-resonant aluminum faceplate, extra internal bracing, copper screws, premium input and output connectors, gold plated RCA terminals, oversized detachable AC cord, reinforced steel chassis, massive feet, and single-piece extruded aluminum heat sinks- just to name a few.

DRX-R1_Main_Inside

High Performance Processing

The DRX-R1.1 employs premium ultramodern digital to analog converters and digital signal processing engines. Three Analog Devices SHRC 32-bit SHARC 32-bit digital signal processors can each handle over 6 billion operations per minute to fully handle the latest in object based surround processing, advanced AccuEQ with AccuReflex room correction and more. Multiple studio reference grade AKM DAC’s (including 768 kHz/32-bit) allow the Reference Series products to fully handle the latest in lossless Hi-Resolution audio formats.

hpp

Integra’s Original Approach to Room Correction

AccuEQ conducts two measurements- one to set the level, the other to set the distance and crossover for ALL speakers, including the subwoofer. In the second round of measurements, your room’s sonic characteristics are evaluated. Using this information, AccuEQ is able to prevent standing waves from forming by adjusting frequency response.

Choose to include or bypass EQ measurement for front left and right speakers, and choose to automatically or manually set the EQ. Further, you can save your own manual EQ settings into three available presets.

The new AccuReflex technology aligns the phase of upfiring «height» speakers with the sound coming directly from your other speakers. Any delay is resolved so that everything arrives at your ears at the same time. The result is cohesive reproduction of object-based soundtracks.

Learn more

AccuEQ

Perfect for Custom Installation

Integra products are designed and engineered to meet the demands of custom audio/video systems installers. Besides Dealer Settings Memory Store and Recall with Lock / Unlock and PC Software Support, the DRX-R1.1 includes system integration connectivity such as RS232 and IP control with support for 2-way communication with 3rd party home automation systems. A pair of infrared (IR) inputs and an IR output make for a clean, reliable installation and allow pass-through of IR signals to control other devices connected to the DRX-R1.1, such as a TV or Blu-ray player. Three fully programmable 12 volt triggers can be used to raise/lower a projection screen, power on/off an external amplifier and open/close the drapes all with the touch of a button. Optional rack mount kits for all full size models provide a clean, finished look when installed in racks and cabinets, especially with the unit’s aluminum faceplate. Integra works closely with control systems partners such as Savant, Crestron, URC, RTI, and Ihiji and supports Control4 Simple Device Discovery Protocol (SDDP) and AMX Device Discovery for simplified system integration.

Home Control Integra
AMPLIFIER:
# Channels 11.2
POWER (8 Ω 20-20kHz 0.08%) / CH 140
Amplifier Frequency Response 5Hz – 100kHz
Wide Range, High Current Power Supply Natural Harmonics Technology, Massive High-Power Transformer
High Instantaneous Current Capability 40 Amps, 1kHz, 00.1 Ω Pulse
THX Certified
Continuous 6 Ω Rated
Low Impedance Drive- Certified 4 Ω
Hand Selected Parts to Ensure Low Impedance Performance Custom- Audio Tuned
Discrete Output Stages for All Channels
All Channels Equal Power Output
Hybrid, High-Current Digital Amplification
Separate Digital and Analog Circuitry to Reduce Interference
Independent Power Supply 2
Bi-amp Capability – Front L/R Channels
PROCESSING:
Dolby Atmos and Dolby Surround
Dolby TrueHD
DTS:X and DTS Neural:X
DTS-HD Master Audio
THX Processing Modes & Loudness Plus
VLSC for Noise Free Signal Path All Channels
AccuEQ Automatic Room Calibration Advanced (Fine Tuned) w/AccuReflex
GAME Surround Modes (Rock, Action, Sports, Role Play)
Advanced Music Optimizer to Enhance Compressed Audio Files
Standing Wave EQ User Defined (x3)
Premium Quality Digital-to-Analog Conversion 384k / 32-bit AKM4490 Differential DAC (Front L/R)
768k / 32-bit AKM4458 Differential DAC (x2, Surround Channels)
32-Bit DSP Chip for Advanced Processing Analog Devices SHARC (x3)
Ultra-Low-Jitter Circuitry to Improve Audio
Adjustable Crossover by Channel Pair 40/45/50/55/60/70/80/90
100/110/120/130/150/180/200 Hz
Accurate Speaker Distance Setting 0.1 – foot
A/V Sync Delay (by Source) -100 to +500 ms
CONNECTIVITY:
HDMI Inputs / Output(s) 8 / 2
4K / 60 Hz 4:4:4 Colorspace Support
Dolby Vision Support
HDCP 2.2 Copy-Protection Compatibility
HLG (Hybrid Log Gamma), HDR10, WCG (Wide Color Gamut) Support
HDMI Support for BT.2020
HDMI Support for 3D, Audio Return Channel and CEC
Enhanced Audio Return Channel (eARC)
HDMI Support for Deep Color, x.v.Color, LipSync
HDMI Support for DVD-Audio, SACD, Multichannel PCM
Front Panel HDMI Input
HDBaseT Output
Analog to HDMI Upconversion From 480i / 576i
4K Upscaling from 1080p via HDMI
Component Video Inputs 2
Composite Video Inputs 2
Digital Audio Inputs (COAX / OPT) 2 / 3
Analog Audio Inputs 7
Phono Input
Front Panel A/V Input
Analog Pre-outs 11.2
Subwoofer Outputs 2 (Discrete)
NETWORK / USB:
Google Chromecast built-in
Google Assistant (Voice Control)
FlareConnect Wireless Multi-Room Audio Streaming Technology
DST Play-Fi
DTS Play-Fi App for iOS and Android Integra Music Control
App Control via iOS and Android-Powered Devices Integra Control Pro
Apple Airplay
iPod / iPhone / iPad Ready
Home Network Music Streaming
TIDAL High Fidelity Music Streaming
Pandora
Spotify
Spotify Connect
TuneIn Radio
Deezer
DSD Support (2.8, 5.6, 11.2 MHz) 2.8, 5.6, 11.2 MHz
Dolby TrueHD Support
Apple Lossless (ALAC) Support
WAV Support
AIFF Support
DSDIFF Support
FLAC Support
MP3 Support
USB Input for Streaming Audio
WiFi Certified
Bluetooth
Firmware Updates via Network and USB
MULTIZONE:
Powered Zone 2
Powered Zone 2 A / B
Powered Zone 3
Fixed or Variable Zone 2 Line Out
Fixed or Variable Zone 3 Line Out
Zone 2 Video Output HDMI
Zone 2 OSD
Zone 2 Audio DAC HDMI (1-5), Coax, Optical, NET, USB
Zone 3 Audio DAC NET, USB
Whole House Mode HDMI (1-5), Coax, Optical, NET, USB, Analog
Remote Play Zone- Selectable Airplay, Spotify Connect
INTEGRATION ACCESS:
Bi-directional RS-232 Control Port
Bi-directional Ethernet Control Port
Rear Panel IR Input / Output 2 / 1
RIHD (Remote Interactive over HDMI)
12V Trigger (with Adjustable delay) x3, Assignable
MISCELLANEOUS:
Research Grade Construction Internal Cross Bracing (x2)
Power Supply Shielding (x2)
Copper Screws (Rear & Internal)
R Grade Power Supply
Transparent Binding Posts
GUI for Setup Menu ✓ (Advanced HD)
Quick Setup Menu
Input Name Edit Fully Customizable
HDMI Standby «Through» Mode Assignable
Dealer Settings Memory Store & Recall Function
Screensaver Function ✓ (Advanced)
Hybrid Standby to Reduce Power Consumption
Smart Grid Ready
Anti-Resonant Aluminum Front Panel
Gold-Plated RCA Terminals
Oversized Detachable AC Cord
Rack Mount Kit Available IRK-180-4C
Warranty 3 YEARS
AMPLIFIER SECTION:
Power Output (8 Ω, 20 Hz-20 kHz, FTC) 140W / Channel (8 Ω)
Dynamic Power 320W / Channel (3 Ω)
270W / Channel (4 Ω)
160W / Channel (8 Ω)
THD (Total Harmonic Distortion + Noise) 0.04% (1 kHz, 100W)
Input Sensitivity and Impedance 200 mV / 82 k-Ω (LINE)
3.5 mV / 47 k-Ω (Phono MM)
Rated RCA Output Level and Impedance 1 V / 330 Ω (Pre Out, Subwoofer Pre Out)
200 mV / 1.2 k-Ω (Zone Out)
2.0 V / 1.2 k-Ω (Zone Pre Out)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz – 100 kHz / +1 dB-3 dB (Direct Mode)
Tone Control ±10dB, 100 Hz (Bass)
±10dB, 10 kHz (Treble)
Signal-to-Noise Ratio 108 dB (Line, IHF-A)
90 dB (Phono)
Speaker Impedance 4 Ω – 16 Ω
VIDEO SECTION:
Signal Level Video: 1.0 Vp-p / 75 Ω (Composite / Component Y)
0.7 Vp-p / 75 Ω (Component Pb / Pr)
TUNER SECTION:
Tuning Frequency Range FM 87.5 MHz – 107.9 MHz
AM 530 kHz – 1,710 kHz
FM / AM Preset Memory 40 Stations
GENERAL:
Power Supply AC 120 V, 60 Hz
Power Consumption 360 W
Stand-by Power Consumption 0.1 W
Dimensions (W X H X D) 17 1/8″ x 7 3/4″ x 17 9/16″
435 x 197 x 446.5 mm
Weight 43.1 lbs. (19.5 kg)
CARTON:
Dimensions (W X H X D) 22 1/4″ x 12 13/16″ x 21 9/16″
565 x 325 x 547 mm
Weight 49.6 lbs. (22.5 kg)
